NE系列斗式提升机
山东新泰德诚机械有限公司NE板链斗式提升机外形及基础安装尺寸表
|
型号
|
NE15
|
NE30
|
NE50
|
NE100
|
NE150
|
NE200
|
|
|
机壳形式
|
I
|
I
|
I
|
I
|
I
|
II
|
|
|
上机壳
|
H1
|
523
|
840
|
665
|
741
|
766
|
968
|
|
H2
|
1342
|
2265
|
1880
|
2000
|
1700
|
1780
|
|
|
卸料口
|
D1
|
900
|
955
|
1100
|
1475
|
1300
|
1650
|
|
D2
|
800
|
1000
|
1000
|
1200
|
1200
|
1500
|
|
|
D3
|
250
|
300
|
350
|
350
|
400
|
550
|
|
|
D4
|
300
|
350
|
400
|
500
|
650
|
650
|
|
|
d1
|
306/3
|
356/3
|
406/3
|
406/3
|
456/3
|
606/4
|
|
|
d2
|
356/3
|
406/3
|
456/3
|
556/4
|
706/5
|
706/5
|
|
|
平台
|
p1
|
1000
|
602
|
777
|
803
|
1200
|
1280
|
|
p2
|
104
|
104
|
104
|
130
|
130
|
144
|
|
|
p3
|
1404
|
2403
|
1827
|
1740
|
1740
|
1864
|
|
|
p4
|
521
|
620
|
616
|
729
|
720
|
870
|
|
|
p5
|
1579
|
2041
|
2236
|
2380
|
23800
|
2730
|
|
|
p6
|
2300
|
2500
|
2500
|
2600
|
3300
|
4100
|
|
|
中间机壳
|
M1
|
1050
|
1240
|
1240
|
1450
|
1450
|
1750
|
|
M2
|
1156
|
1340
|
1348
|
1598
|
1582
|
1888
|
|
|
M3
|
450
|
500
|
650
|
800
|
1060
|
1120
|
|
|
M4
|
556
|
600
|
780
|
948
|
1196
|
1280
|
|
|
M5
|
1250
|
1440
|
1440
|
1680
|
1680
|
1980
|
|
|
M6
|
650
|
700
|
850
|
1030
|
1290
|
1350
|
|
|
喂料口
|
R1
|
800
|
970
|
970
|
1125
|
1075
|
1300
|
|
R2
|
250
|
300
|
280
|
400
|
500
|
550
|
|
|
R3
|
250
|
300
|
300
|
400
|
600
|
560
|
|
|
R4
|
1350
|
1650
|
1700
|
2000
|
2050
|
2400
|
|
|
r1
|
306/3
|
356/3
|
336/3
|
456/3
|
556/4
|
620/4
|
|
|
r2
|
306/3
|
356/3
|
356/3
|
456/3
|
656/5
|
630/4
|
|
|
下机壳
|
B1
|
600
|
750
|
750
|
850
|
900
|
1050
|
|
B2
|
2440
|
2440
|
2500
|
2500
|
2500
|
3000
|
|
|
B3
|
830
|
970
|
996
|
1148
|
1632
|
2102
|
|
|
基础尺寸
|
Z1
|
1000
|
1200
|
1200
|
1400
|
1400
|
1670
|
|
Z2
|
1400
|
1500
|
1500
|
1700
|
1700
|
1850
|
|
|
Z3
|
950
|
1000
|
1100
|
1200
|
1350
|
1350
|
|
|
Z4
|
1300
|
1400
|
1700
|
1900
|
2350
|
2350
|
|
|
Z5
|
554
|
594
|
744
|
916
|
1176
|
1250
|
|
|
Z6
|
400/1
|
450/1
|
550/1
|
600/1
|
400/1
|
800/1
|
|
|
Z7
|
1144
|
1334
|
1334
|
1566
|
1566
|
1880
|
|
|
Z8
|
500/1
|
600/1
|
600/1
|
700/1
|
700/1
|
940/
|
|
